Alpha Technologies Cordex HP CXRF Rectifier 48-2.0kW
The Alpha Technologies Cordex HP CXRF 48-2.0kW is a high-performance, fan-cooled switch-mode rectifier designed for demanding telecommunications applications. It provides efficient and reliable DC power and is backward compatible with Cordex 1.8kW power systems, allowing for easy upgrades.
High efficiency: With up to 94% efficiency, the rectifier reduces operating expenses and lowers your carbon footprint.
Wide AC input range: The rectifier has a universal input that is compatible with 120/208/220/240Vac 50/60Hz electrical service for global deployment flexibility.
Compact design: Its small, 2RU (rack unit) form factor and high power density (21.8W/in³) allow for installation in space-restricted environments.
High-temperature operation: The Cordex HP series is built to operate reliably in harsh outdoor environments, such as enclosures.
Hot-swappable: The modular design allows you to add or replace rectifier modules without shutting down the system.
Digital control: The rectifier is managed via a Cordex CXC system controller, which provides local and remote setup, adjustment, and monitoring through a web browser.
System upgrade path: The module is backward compatible with existing Cordex 1.8kW shelves, offering a seamless and cost-effective way to increase power density.
Ideal applications
This rectifier is suitable for small-to-medium 48Vdc power applications, including:
